Go beyond dashcams
Commercial fleets need connected safety records, not only post-incident video playback.
Link video with vehicle events
Support driver behavior review
IVT-02 SMART ON-BOARD RECORDER
SMART ON-BOARD RECORDER
Multi-Camera Fleet Safety and Driving Data Management
SMART ON-BOARD RECORDER
Multi-Camera Fleet Safety and Driving Data Management
Fleet safety needs connected evidence, not a standard dashcam.
01 / Sensing Node
01
Install and connect vehicle inputs
IVT-02 is installed inside a large vehicle or commercial vehicle and connected to multiple cameras, vehicle signal inputs, storage devices, and mobile communication modules. Once the vehicle is powered on, the system can start continuous recording and trigger event recording based on configured conditions.
02 / Transmission
02
Preserve and report driving events
When sudden braking, reversing, turning, speed changes, gravity changes, or other defined events occur, IVT-02 can preserve related video and event data. With 4G/5G connectivity, selected event information can be reported to the management platform. When optional external GPS is configured, the system can also support vehicle location and route traceability.
03 / Application
03
Support fleet safety management
By integrating multi-camera video, vehicle signals, sensor data, and mobile connectivity, IVT-02 helps fleets move from post-incident video review to systematic driving event, driver behavior, and safety risk management.
multi-camera fleet safety and event recording
IVT-02connectsuptoeightcamerachannels,vehiclesignals,event-triggeredrecording,ADAS,and4G/5Greportingforcommercialfleetsafetymanagement.
1
Install and connect vehicle inputs
IVT-02 is installed inside a large vehicle or commercial vehicle and connected to multiple cameras, vehicle signal inputs, storage devices, and mobile communication modules. Once the vehicle is powered on, the system can start continuous recording and trigger event recording based on configured conditions.
2
Preserve and report driving events
When sudden braking, reversing, turning, speed changes, gravity changes, or other defined events occur, IVT-02 can preserve related video and event data. With 4G/5G connectivity, selected event information can be reported to the management platform. When optional external GPS is configured, the system can also support vehicle location and route traceability.
3
Support fleet safety management
By integrating multi-camera video, vehicle signals, sensor data, and mobile connectivity, IVT-02 helps fleets move from post-incident video review to systematic driving event, driver behavior, and safety risk management.
07:56
LTE41%
T20-2CN
Fleet Temperature Monitor
Cold-Chain Compliance
78
%
In 46Warn 4Breach 4Off 1
MapFleetTempLogs
Fleet Safety & Incident Intelligence
Centralize in-vehicle safety events and driver behavior data for fleet operations
IVT-02 transmits in-vehicle video events, ADAS warnings, and safety records to IoT View or compatible backend platforms, supporting incident review, driver behavior monitoring, and fleet risk management.
This is where operators review threshold alerts, trace historical records, and turn distributed field readings into a single operational view.
INSIGHTS
Fleet Intelligence
Manage risk in motion
Plan how video, events, and vehicle signals support fleet safety and incident review.
Cover large vehicles
Multi-camera input helps fleets see blind spots, loading zones, and vehicle surroundings.
Support up to 8 camera channels
Improve turning and reversing review
Protect sensitive transport
Event data and optional GPS can support high-value, cold chain, or security transport.
Record abnormal transport events
Reduce dispute and cargo risk
KEY ADVANTAGES
Key Advantages
Select an advantage to see how the product supports practical, repeatable field deployment.
IVT-02 supports up to 8 camera inputs for front, rear, side, cabin, and blind-spot views, helping fleets improve turning, reversing, stopping, loading, unloading safety, and post-incident evidence for buses, logistics, trucks, and special vehicles.
VERSIONS
Configurations & Versions
Model variants organized by field condition and connection profile.
V01Sensor Variant
IVT-02 + Multi-Camera Setup
Best FitBuses, trucks, logistics vehicles, construction vehicles
V02Sensor Variant
IVT-02 + 4G/5G Reporting
Best FitFleets requiring remote event reporting and centralized management
V03Sensor Variant
IVT-02 + ADAS
Best FitLong-haul fleets, large vehicles, high-risk operations
V04Sensor Variant
IVT-02 + Optional GPS
Best FitVehicle location, route, and mission traceability
V05Sensor Variant
IVT-02 + UBI Data Application
Best FitInsurance, fleet risk scoring, driver safety programs
V06Sensor Variant
IVT-02 Pilot Deployment
Best FitPoC, fleet upgrade evaluation, early-stage deployment
SPECIFICATIONS
SPECIFICATIONS
Model
IVT-02
Product Name
Smart On-board Recorder
Product Type
In-vehicle video recording and driving data management device
Video Input
Up to 8 camera channels
Video Output
VGA / AHD-TVI / CVBS, subject to final product configuration
Output Interface
VGA × 1, subject to final product configuration
Video Compression
AVC H.264 / HEVC H.265
Audio Format
PCM / AAC
Recording Mode
Automatic continuous recording after power-on; event-triggered recording
Resolution
1080P / 720P / 480P, configurable by requirement
Storage Device
SATA M.2 SSD, SD / SDHC / Micro SD, 8GB eMMC
Wireless Network
4G / 5G, Nano SIM; supported bands subject to final product configuration
GPIO IN
ACC / Left Signal / Right Signal / Reverse Gear / Brake / Speed Pulse
GPS
Optional external GPS
ADAS
ADAS driver assistance supported; final scope depends on project configuration
USB Interface
USB Slot × 2
FAQ
FAQ
Get Started / Project Evaluation
Ready to evaluate IVT-02?
Move fleet safety beyond post-incident video review. With IVT-02, operators can manage driving events, driver behavior, and operational risk with a more complete in-vehicle video and data workflow. Whether you manage buses, logistics fleets, freight trucks, construction vehicles, special-purpose vehicles, municipal fleets, or high-value transport operations, NHR can help design the right IVT-02 deployment based on vehicle type, camera requirements, connectivity environment, data retention rules, and platform integration needs.
